MCB 1 Pole 6kA 10A | C Curve

The 1 Pole 6kA 10A C Curve MCB is a miniature circuit breaker designed for effective protection of electrical circuits against overloads and short circuits. With a C curve tripping characteristic, this MCB is suitable for general-purpose use, especially where moderate inrush currents are expected—such as in lighting and small motor applications.

Rated at 10 amps, it is ideal for residential, commercial, and light industrial installations. It features a 6kA short-circuit capacity, making it compliant with most Australian and international standards for reliable operation in typical load environments.

Key Features:

• 10A Rated Current: Ideal for lighting and light appliance circuits

• C Curve Tripping: Suitable for moderate inrush current protection

• 6kA Breaking Capacity: Protects against short circuits up to 6000 amps

• 1 Pole (1P): Single-phase use in standard distribution boards

• Thermal-Magnetic Protection: Ensures fast response to overload and fault conditions

• Compact DIN Rail Mount: Quick and easy installation

• Switching Indicator: Visual on/off status display

• Standards Compliant: AS/NZS and IEC certified

Specifications:

• Rated Current: 10A

• Poles: 1P (single pole)

• Breaking Capacity: 6kA

• Tripping Curve: C Curve

• Voltage Rating: 230/400V AC

• Mounting: DIN rail

• Standards: AS/NZS 60898, IEC 60898

• Application: Lighting circuits, domestic and light commercial loads
