F Male to F Male Quick Connector

The F Male to F Male Quick Connector is a compact, easy-to-use coaxial adapter designed for joining two F-Type female connectors. Ideal for satellite, cable TV, and antenna systems, this quick connector enables a secure and reliable connection without the need for tools or permanent fittings. Its precision-machined threads ensure a snug fit, while its nickel-plated brass construction guarantees excellent signal conductivity and corrosion resistance. Perfect for in-line coupling, testing setups, or extending coaxial cables in both residential and commercial installations.

Key Features:

• Joins two F-Type female connectors

• F Male to F Male design with quick-connect convenience

• Ideal for satellite, terrestrial, and cable TV systems

• Durable nickel-plated brass body for corrosion resistance

• Tool-free installation and removal

• Compact and reusable – perfect for temporary setups or testing

• Minimal signal loss for optimal performance

• Suitable for indoor and outdoor use (when properly protected)

Specifications:

• Connector Type: F Male to F Male

• Material: Nickel-plated brass

• Impedance: 75 Ohm

• Frequency Range: Up to 3 GHz

• Insertion Loss: ≤ 0.2 dB

• Length: Approx. 33 mm

• Outer Diameter: Approx. 10 mm

• Operating Temperature: –20°C to +60°C
