Multi Switch 5 Input 12 Output

The Multiswitch 5 Input 12 Output is a high-performance signal distribution solution designed for both satellite and terrestrial TV systems. With five inputs (typically 4 satellite polarities + 1 terrestrial) and twelve outputs, this multiswitch is ideal for multi-dwelling units, apartment blocks, and commercial installations requiring reliable signal delivery to multiple receivers.

It efficiently combines satellite and free-to-air (FTA) signals and distributes them to up to 12 individual outlets. Engineered for minimal signal loss, high isolation, and strong signal integrity, this multiswitch ensures consistent performance across all connected devices. Suitable for Foxtel, VAST, and FTA-compatible systems.

Key Features:

• 5 Inputs – Supports 4 satellite inputs (H/L, H/H, V/L, V/H) plus 1 terrestrial input.

• 12 Outputs – Distributes signals to 12 receivers simultaneously.

• High Isolation – Prevents cross-talk and maintains signal quality between outputs.

• Low Insertion Loss – Optimised to reduce signal degradation.

• Active Terrestrial Input – Ensures strong FTA signal amplification.

• Power Pass on SAT Lines – Allows LNB powering via satellite receivers.

• Compatible with DiSEqC and Tone Switching – For seamless satellite signal selection.

• Compact & Durable Design – Robust metal housing for long-term reliability.

Specifications:

• Inputs: 4x Satellite (13/18V, 0/22kHz) + 1x Terrestrial

• Outputs: 12

• Frequency Range:

  • Satellite: 950–2400 MHz

  • Terrestrial: 47–862 MHz

• Insertion Loss:

  • Satellite: Typically <4 dB

  • Terrestrial: Typically <10 dB

• Isolation Between Outputs: >25 dB

• Impedance: 75 Ohm

• DC Pass: On selected satellite ports to power LNB

• Power Supply: External (e.g. 18V DC – varies per unit)

• Mounting: Wall or rack mountable

• Operating Temperature: -10°C to +50°C

• Dimensions: Approx. 265 mm (L) x 150 mm (W) x 55 mm (H)

• Connector Type: F-Type

• Approval: Suitable for Foxtel and VAST installations
