ATEN 24 Port 240V 15A IP56 Captive Plug | PDU

The ATEN NRGence PE1224mG Energy PDU is a professional high-density vertical Power Distribution Unit designed to deliver reliable 240 V AC power distribution across data centres, server rooms, telecommunications cabinets and enterprise network infrastructure.

Featuring 24 total outlets – 12 × Australian 15 A outlets and 12 × IEC C13 outlets – the PE1224mG provides excellent flexibility for powering a combination of servers, network switches, storage systems, communications equipment and other rack-mounted devices from one streamlined PDU.

This configuration is supplied with a 15 A IP56 Captive Plug, providing a robust and secure input connection for professional commercial and communications installations. The PE1224mG is rated for 15 A maximum input current with a maximum input power of 3,600 VA at 240 V AC.

An integrated current meter provides convenient local load monitoring, helping technicians manage rack power utilisation and reduce the risk of overload. The dedicated Energy Sensor Port supports connection to an ATEN EC1000 Energy Box for additional power monitoring, while the integrated 15 A branch circuit breaker provides essential overload protection.

With its slim 1,437 × 45 × 60 mm vertical design, mixed Australian and IEC outlet configuration and professional monitoring capabilities, the PE1224mG delivers power, flexibility and visibility while preserving valuable rack space.

The outlet configuration, electrical ratings, monitoring functions and dimensions are specified in the supplied ATEN PE1224mG documentation. The 15 A IP56 Captive Plug is the supplied configuration you have specified for your unit.

Key Features

• 24 total power outlets
• 12 × Australian 15 A outlets
• 12 × IEC C13 outlets
• 15 A IP56 Captive Plug
• 240 V AC nominal input voltage
• 15 A maximum input current
• Maximum input power of 3,600 VA
• Mixed Australian and IEC outlet configuration
• Integrated current meter for local load monitoring
• Dedicated ATEN Energy Sensor Port
• Compatible with ATEN EC1000 Energy Box for additional monitoring
• 15 A branch circuit breaker for overload protection
• Slim vertical rack-mount design
• High-density power distribution without consuming valuable horizontal rack space
• Designed for professional IT and telecommunications environments

Specifications

Applications

• Data centres
• Server rooms
• 19-inch server and network cabinets
• Telecommunications racks
• Enterprise IT infrastructure
• Servers and storage systems
• Network switches and routers
• Fibre and communications equipment
• Security and surveillance systems
• Professional AV installations
• Network operations centres
• Industrial IT environments
• Critical communications infrastructure
