RCBO 1P+N 6kA 32A 30mA | 2 Screw Type A

The RCBO 1P+N 6kA 32A 30mA Type A (2-Screw) is a compact and reliable residual current circuit breaker with overcurrent protection, designed to safeguard electrical circuits from both overloads, short circuits, and earth leakage faults.

Combining the function of an MCB and RCD in a single module, this RCBO is ideal for residential and light commercial applications. With a 2-screw terminal design, it ensures fast and secure installation. Type A sensitivity detects both AC and pulsating DC earth leakage currents, providing enhanced safety for modern appliances and electronic devices.

Key Features:

• Integrated Protection: Combines MCB and RCD in one device

• 6kA Breaking Capacity: Handles high fault currents safely

• Type A RCD: Detects AC and pulsating DC leakage

• Rated Current: 32A – suitable for moderate load circuits

• 30mA Trip Sensitivity: Provides personal protection from electric shock

• 1P+N Configuration: Protects both active and neutral conductors

• 2-Screw Terminals: Secure, fast installation

• DIN Rail Mountable: Fits standard switchboards and enclosures

• AS/NZS Compliant: Meets Australian standards for electrical safety

Specifications:

• Poles: 1P+N

• Rated Current (In): 32A

• Breaking Capacity: 6kA

• Residual Current Sensitivity (IΔn): 30mA

• RCD Type: Type A

• Mounting: DIN rail

• Terminal Type: 2-screw

• Voltage Rating: 230V AC

• Standards: AS/NZS 61009, IEC 61009-1
