RCBO 3P+N 10KA 20A 30MA 4MOD | C Curve Type

The RCBO 3P+N 20A 30mA 10kA Type C Curve is a four-module, DIN rail–mounted circuit breaker designed for three-phase electrical systems. It provides combined protection against earth leakage, overload, and short-circuit conditions, making it ideal for commercial and industrial environments.

Rated at 20A with a residual current sensitivity of 30mA, this RCBO instantly disconnects the power in the event of a fault, helping to prevent electric shock and equipment damage. The 10kA breaking capacity ensures safe operation under high fault current conditions, while the C Curve trip characteristic is ideal for circuits with moderate inrush current, such as motor-driven or mixed load applications.

Key Features:

• 3P+N (Three-Phase + Neutral): Suitable for commercial and industrial power systems

• 20A Rated Current: Ideal for light to medium power loads

• 30mA RCD Sensitivity: Fast earth leakage protection for personnel and equipment

• 10kA Breaking Capacity: Handles high fault currents safely

• Type C Curve: Designed for circuits with moderate inrush currents

• 4 Module Width: Compact DIN rail mounting in distribution boards

• Visual Indicators: Clear ON/OFF and trip status indicators

• Standard Compliance: Meets IEC/EN 61009-1 and AS/NZS standards

• Application Areas: Lighting, HVAC, motors, industrial panels

Specifications:

• Poles: 3P+N

• Rated Current: 20A

• Trip Sensitivity: 30mA

• Breaking Capacity: 10kA

• Tripping Curve: Type C

• Modules: 4 DIN

• Voltage Rating: 400V AC

• Frequency: 50/60Hz

• Mounting: DIN rail

• Standards: IEC/EN 61009-1, AS/NZS
